1 2

AMPS

L12100

L12100

£192.24 GBP
£192.24 GBP
Sale Sold out
Taxes included.

AL series LiFePO4 - Lithium Iron Phosphate batteries.

Spec list

12V Batteries

Charge Discharge
Part No Ah Capacity Current (A) (max) Current (A) (max) Dimensions (cm) LWH Weight (Kg) Battery Terminal
AL1220 20Ah 20A 40A 19 x 7.7 x 18.7 2 M5 5mm
AL1275 75Ah 40A 80A 28 x 17.6 x 17.2 8 T1 DIN
AL1280 80Ah 60A 140A 26 x 21 x 16.5 11 8mm M8
AL12100 100Ah 100A 100A 26 x 17 x 21 9.6 8mm M8
L12100 105Ah 100A 100A 26 x 17.6 x 17.6 9.6 8mm | T1DN
AL12120 120Ah 80A 150A 41 x 23.5 x 17 15 8mm M8
AL12150 150Ah 80A 150A 41 x 23.5 x 17 18 8mm M8
AL12300 300Ah 150A 300A 53.2 x 23.7 x 21.5 28 8mm M8



12V Heated models

LH1270 70Ah 50A 50A 22.5 x 140 x 210 6.6 8mm M8
LH12100 100Ah 100A 100A 26 x 17 x 21 9.6 8mm M8
LH12120 120Ah 120A 120A 330 x 215 x 17.5 13kg 8mm M8
LH12400 400Ah 300A 300A 520 x 267 x 220  36kg 8mm M8
LH12500 500Ah 300A 300A 520 x 267 x 220  42kg 8mm M8




Part No Nominal Voltage Charge Current Discharge current Nominal Capacity Actual Capacity
AL1220 12V 10A 20A 20Ah 20Ah
AL1260 12V 50A 120A 60Ah 60Ah
AL1280 12V 60A 140A 80Ah 86Ah
AL12100 12V 70A 150A 100Ah 100Ah
AL12120 12V 80A 150A 120Ah 120Ah
AL12150 12V 100A 150A 150Ah 150Ah
AL12200 12V 150A 300A 200Ah 200Ah
AL12300 12V 150A 300A 300Ah 300Ah
AL2450 24V 80A 40A 50Ah 50Ah
AL24150 24V 80A 150A 150Ah 150Ah
AL3650
 36V
 100A
 100A
 50Ah
 50Ah
LH4840
 48V
 50A
 50A
 50Ah
 50Ah
AL48100 48V 100A 100A 100Ah 102Ah
LH48125
 48V
 120A
 200A
 125Ah
 125Ah

12V 150Ah model is in the same box as the 120Ah battery. We have just managed to fit more cells into the same volume. Therefore, you get higher energy density.





Battery Information PDF - including Bluetooth

We are constantly updating our battery range and specifications.

The battery information PDF is prone to change. We endeavour to keep this updated.
